BLUE RIDGE 500-I

Name: BLUE RIDGE 500-I
Brand: Englander
SKU: ESW0014
Price: 2499.00 CAD
Availability: InStock

Englander

SKU: ESW0014

48 products in stock

$2,499.00 CAD

Quantity: (In cart: 0)

Increments of 1 Minimum of 1 Maximum of

Full Description

🌍 Made in:

Canada

United States

📏 Dimension: 50"L X 28 7/8"P X 32"H

🏠 Heating Area: 1,000 - 2,700 ft²

🔥 Maximum Log Length: 22" oriented East-West

Full Specifications

Specifications

Appliance Performance

Fuel type	Dry cordwood (16" recommended)	Maximum overall heat output rate	57,800 BTU/h (16.9 kW)
Heating area	1,000 - 2,700 ft²	Average overall efficiency - dry cordwood (HHV)	71 %
Overall firebox volume	3.5 ft³	Average overall efficiency - dry cordwood (LHV)	76 %
EPA loading volume	2.88 ft³	Optimum efficiency	77 %
Maximum burn time	10 h	Optimum heat transfer efficiency	75 %
Maximum heat output - dry cordwood	110,000 BTU/h	Average particulate emission rate	1.6 g/h
Minimum overall heat output rate	17,200 BTU/h (5.0 kW)	Average CO	73 g/h

General Features

Mobile home approved	No	Steel thickness-body	3/16"
Premium quality blower included (CFM)	144	Steel thickness-top	3/8"
Certified according to applicable standards	By an accredited laboratory (CAN/USA)	Firebox size (Width)	22 7/8"
Combustion technology	Non-catalytic	Firebox size (Height)	13"
Stainless-steel secondary-air system	Yes	Firebox size (Depth)	20 1/8"
Flue outlet diameter	6"	Maximum log length	22" oriented East-West
Distance-center of the flue outlet to back unit	7 1/8"	Log positioning	Loading over width and over depth
Distance-center of the flue outlet to side unit	14 3/8"	Firebox lined with refractory bricks	Yes
Recommended chimney diameter	6"	Baffle type	High quality vermiculite
Type of chimney	Liner ULC-S635, CAN/ULC-S640, UL 1777	Minimum fireplace opening (Width)	31"
Minimum chimney height	12'	Minimum fireplace opening (Height)	26 1/4"
Overall dimension (Width)	50"	Minimum fireplace opening (Depth)	18 3/8"
Overall dimension (Height)	32"	High-efficiency certified appliance	Yes, EPA 2020 approved
Overall dimension (Depth)	28 7/8"	Canadian Standard (emissions)	CSA B415.1-10
Door type	Single, glass with cast iron frame	USA Standard (emissions)	EPA
Door opening size (Width)	19"	Canadian Standard (safety)	ULC S628
Door opening size (Height)	10 5/8"	USA Standard (safety)	UL 1482, UL 737
Glass type	Ceramic glass	Warranty	Limited 5 years
Glass surface - W x H	16 5/8" x 11 3/4"	Shipping weight	520 lb (236 kg)

Clearances

	Canada	United States
Clearance - Combustible side wall to unit	19"	19"
Clearance - Combustible side mantle to unit	9"	9"
Clearance - Combustible top mantle to unit	27"	27"
Clearance - Top of the unit to a 12" combustible mantle shelf	27"	27"
Clearance - Base of the unit to ceiling**	84"	84"

Manuals & Instructions

Consult the available manuals and leaflets for more information on performance, installation and use requirements, etc.

📄 Installation & User's Manual 🔗 📄 Installation & Operation Requirements 🔗 📄 Appliance dimensions 🔗
