BLUE RIDGE 150-I
BLUE RIDGE 150-I

BLUE RIDGE 150-I

Englander
SKU: ESW0006
8 products in stock
$1,929.00 CAD
$1,929.00 CAD

Full Description
🌍 Made in: Canada Flag Canada USA Flag United States
📏 Dimension: 27 7/8"L X 21 7/8"P X 20 1/8"H
🏠 Heating Area: 250 - 1,200 ft²
🔥 Maximum Log Length: 17" (16" recommended)
Full Specifications
Specifications

Appliance Performance

Fuel type Dry cordwood (16" recommended) Maximum overall heat output rate 31,700 BTU/h (9.29 kW)
Heating area 250 - 1,200 ft² Average overall efficiency - dry cordwood (HHV) 75%
Overall firebox volume 1.1 ft³ Average overall efficiency - dry cordwood (LHV) 80%
EPA loading volume 1.03 ft³ Optimum efficiency 82%
Maximum burn time 7 h Optimum heat transfer efficiency 78%
Maximum heat output - dry cordwood 45,000 BTU/h Average particulate emission rate 1.5 g/h
Minimum overall heat output rate 8,471 BTU/h (2.48 kW) Average CO 34 g/h

General Features

Mobile home approved No Steel thickness-top 3/16"
Premium quality blower included (CFM) 90 CFM included Firebox size (Width) 16 3/8"
Certified according to applicable standards CAN/USA accredited laboratory Firebox size (Height) 8 3/4"
Combustion technology Non-catalytic Firebox size (Depth) 12 3/8"
Stainless-steel secondary-air system Yes Maximum log length 17" (16" recommended)
Flue outlet diameter 6" Log positioning Loading over width
Distance-center of the flue outlet to back unit 5" Firebox lined with refractory bricks Yes
Distance-center of the flue outlet to side unit 10 3/8" Baffle type High quality vermiculite
Recommended chimney diameter 6" Minimum fireplace opening (Width) 25"
Type of chimney Liner ULC-S635, CAN/ULC-S640, UL 1777 Minimum fireplace opening (Height) 19"
Minimum chimney height 12' Minimum fireplace opening (Depth) 15 1/2"
Overall dimension (Width) 27 7/8" High-efficiency certified appliance Yes, EPA 2020 approved
Overall dimension (Height) 20 1/8" Canadian Standard (emissions) CSA B415.1-10
Overall dimension (Depth) 21 7/8" USA Standard (emissions) EPA
Door type Single, glass with cast iron frame Canadian Standard (safety) ULC S628
Door opening size (Width) 18 1/4" USA Standard (safety) UL 1482, UL 737
Door opening size (Height) 7 7/8" Warranty Limited 5 years
Glass type Ceramic glass Shipping weight 295 lb (134 kg)
Glass surface - W x H 17 3/8" x 8 1/8" Minimum fireplace opening (Height at the back) 17 1/4"
Steel thickness-body 3/16" Minimum fireplace opening (Width at the back) 21 1/2"

Clearances

Canada United States
Clearance - Combustible side wall to unit 19" 19"
Clearance - Combustible side mantle to unit 1" 1"
Clearance - Combustible top mantle to unit 1" 1"
Clearance - Top of the unit to a 12" combustible mantle shelf 34" 34"
Clearance - Base of the unit to ceiling** 72" 72"
Clearance - Floor protection in front of the unit (from door opening) 16" 18"
Manuals & Instructions
