ECO-65R

SKU: DP00061
Sale price $4,629.00 CADRegular price $4,879.00 CAD
Regular price $4,629.00 CAD
In stock
ECO-65R
ECO-65R
Sale price $4,629.00Regular price $4,879.00
Regular price $4,629.00
Trust Badge
Made in Canada Flag Canada
Dimension 24"L X 34 3/8"P X 41"H
Heating Area 800 - 2,600 ft² How to Calculate Heating Area
Maximum Burn Time 105 h
Full Specifications

Full Description
Specifications

Appliance Performance

Fuel type Pellet (Premium grade or better) Maximum average overall efficiency (LHV) 84.4 %
Heating area 800 - 2,600 ft² Optimum efficiency 84.4%
Hopper capacity 125 lb (57 kg) Optimum heat transfer efficiency 81 %
Maximum burn time 105 h Burn rate 1.12 - 4.63 lb/h
Maximum heat input rate 50,800 BTU/h (14.8 kW) Average particulate emission rate 0.77 g/h
Minimum overall heat output rate 6,966 BTU/h (2.04 kW) Average CO 12.96 g/h
Maximum overall heat output rate 28,540 BTU/h (8.36 kW) Average electrical power consumption for ignition cycle 3.7A (360 W)
Minimum average overall efficiency (HHV) 76.7 % Average electrical power consumption for continuous operation 2.15 - 2.9 A (258 - 348 W)

General Features

Alcove installation approved Yes Noise level at 6 feet 53 dBa (+/- 3 dBa) - 59 dBa (+/- 3 dBa)
Mobile home approved Yes, with fresh air intake Door type Single, glass with cast iron frame
Certified according to applicable standards By an accredited laboratory (CAN/USA) Glass type Ceramic glass
Premium quality blower included (CFM) CFM included Glass surface - W x H 13 5/8" x 8 1/2"
Combustion technology Top-feed High-efficiency certified appliance Yes, EPA 2020 approved
Baffle type Stainless steel Canadian Standard (emissions) CSA B415.1-10
Flue outlet diameter 4" USA Standard (emissions) EPA, ASTM E2779
Recommended chimney diameter 4" Canadian Standard (safety) ULC S627
Type of chimney ULC/ORD-C441, CAN/ULC S609, UL 641 (TYPE L) USA Standard (safety) UL 1482, ASTM E1509
Overall dimension (Width) 24" Warranty Limited lifetime
Overall dimension (Height) 41" Shipping weight 440 lb (200 kg)
Overall dimension (Depth) 34 3/8" Approved as add-on to an existing furnace No
Voltage and frequency 120 VAC / 60 Hz

Clearances

Canada United States
Clearance - Back wall 3" 3"
Clearance - Side wall 6" 6"
Clearance - Corner 3" 3"
Clearance - Base of the unit to ceiling 72" 72"
Manuals & Instructions
Replacement Parts

Browse all available replacement parts for this model.
