| Alcove installation approved |
Yes |
Noise level at 6 feet |
47 dBa (+/- 3 dBa) - 60 dBa (+/- 3 dBa) |
| Mobile home approved |
Yes, with fresh air intake |
Door type |
Single, glass with cast iron frame |
| Certified according to applicable standards |
By an accredited laboratory (CAN/USA) |
Glass type |
Ceramic glass |
| Premium quality blower included (CFM) |
176 CFM included |
Glass surface - W x H |
15 3/4" x 8 1/8" |
| Combustion technology |
Top-feed |
High-efficiency certified appliance |
Yes, EPA 2020 approved |
| Baffle type |
Stainless steel |
Canadian Standard (emissions) |
CSA B415.1-10 |
| Flue outlet diameter |
3" |
USA Standard (emissions) |
EPA, ASTM E2779 |
| Recommended chimney diameter |
3" | 4" |
Canadian Standard (safety) |
ULC S627 |
| Type of chimney |
ULC/ORD-C441, CAN/ULC S609, UL 641 (TYPE L) |
USA Standard (safety) |
UL 1482, ASTM E1509 |
| Overall dimension (Width) |
25 1/4" |
Warranty |
Limited lifetime |
| Overall dimension (Height) |
32 5/8" |
Shipping weight |
277 lb (126 kg) |
| Overall dimension (Depth) |
29 1/2" |
Approved as add-on to an existing furnace |
No |
| Voltage and frequency |
120 VAC / 60 Hz |
|
|
