BLUE RIDGE 500

Name: BLUE RIDGE 500
Brand: Englander
SKU: ESW0012
Price: 2299.00 CAD
Availability: InStock

SKU: ESW0012

142 products in stock

$2,299.00 CAD

Quantity: (In cart: 0)

Increments of 1 Minimum of 1 Maximum of

Full Description

🌍 Made in:

Canada

United States

📏 Dimension: 28 1/8"L X 31 1/4"P X 35 1/8"H

🏠 Heating Area: 1,000 - 2,700 ft²

🔥 Maximum Log Length: 22" oriented East-West

Full Specifications

Specifications

Fuel type	Dry cordwood (16" recommended)	Maximum overall heat output rate	57,800 BTU/h (16.9 kW)
Heating area	1,000 - 2,700 ft²	Average overall efficiency - dry cordwood (HHV)	71 %
Overall firebox volume	3.5 ft³	Average overall efficiency - dry cordwood (LHV)	76 %
EPA loading volume	2.88 ft³	Optimum efficiency	77 %
Maximum burn time	10 h	Optimum heat transfer efficiency	75 %
Maximum heat output - dry cordwood	110,000 BTU/h	Average particulate emission rate	1.6 g/h
Minimum overall heat output rate	17,200 BTU/h (5.0 kW)	Average CO	73 g/h

Alcove installation approved	Yes	Glass type	Ceramic glass
Mobile home approved	Yes, with fresh air intake	Glass surface - W x H	16 5/8" x 11 3/4"
Certified according to applicable standards	By an accredited laboratory (CAN/USA)	Steel thickness - body	3/16"
Overall dimension (Width)	28 1/8"	Steel thickness-top	5/16"
Overall dimension (Height)	35 1/8"	Firebox size (Width)	22 7/8"
Overall dimension (Depth)	31 1/4"	Firebox size (Height)	13"
Premium quality blower included (CFM)	Optional	Firebox size (Depth)	20 1/8"
Combustion technology	Non-catalytic	Log positioning	Loading over width and over depth
Stainless-steel secondary-air system	Yes	Maximum log length	22" oriented East-West
Flue outlet diameter	6"	Firebox lined with refractory bricks	Yes
Distance - center of the flue outlet to back unit	8"	Baffle type	High quality vermiculite
Distance - center of the flue outlet to side unit	14 1/8"	High-efficiency certified appliance	Yes, EPA 2020 approved
Recommended chimney diameter	6"	Canadian Standard (emissions)	CSA B415.1-10
Type of chimney	CAN/ULC S629, UL 103 HT (2100 °F)	USA Standard (emissions)	EPA
Minimum chimney height	12'	Canadian Standard (safety)	ULC S627
Door type	Single, glass with cast iron frame	USA Standard (safety)	UL 1482, UL 737
Door opening size (Width)	19"	Warranty	5 years limited
Door opening size (Height)	9 7/8"	Shipping weight	480 lb (218 kg)

Manuals & Instructions

Consult the available manuals and leaflets for more information on performance, installation and use requirements, etc.
