| High-efficiency certified appliance |
CSA B415.1-10 approved for Canada |
Glass surface - W x H |
12 3/8" x 10 1/8" |
| Certified according to applicable standards |
By an accredited laboratory (CAN/USA) |
Baffle type |
C-Cast or equivalent |
| Premium quality blower included (CFM) |
Included |
Firebox size (Width) |
17" |
| Blower (hp | speed | CFM)
|
1/4 | 4 | 1,800 |
Firebox size (Height) |
16 1/8" |
| Stainless-steel secondary-air system |
Yes |
Firebox size (Depth) |
22 5/8" |
| Flue outlet diameter |
6" |
Maximum log length |
21" |
| Recommended chimney diameter
|
6" |
Log positioning |
Loading over depth |
| Type of chimney |
CAN/ULC S629, UL 103 HT (2100 °F) |
Firebox lined with refractory bricks |
Yes |
| Overall dimension (Width) |
33 1/4" |
Steel thickness-top |
1/4" |
| Overall dimension (Height)
|
63 1/2" min. |
Steel thickness-body |
3/16" |
| Overall dimension (Depth)
|
49 1/8" |
Filter - Dimensions (Width x Height x Depth) |
15" x 20" x 1" (option) |
| Evacuation direction |
Horizontal |
Hot air plenum - Minimum height of the furnace with plenum |
63 1/2" min. for 72" ceiling | 73" min. for a ceiling higher than 84" |
| Distance-center of the flue outlet to floor |
35 5/8" |
Hot air plenum - Height (minimum - maximum) |
22 3/8" x 26 7/8" |
| Distance-center of the flue outlet to side unit |
13" |
Canadian Standard (safety) |
CAN/CSA B366.1 |
| Door type |
Single, glass with cast iron frame |
USA Standard (safety) |
UL 391 |
| Door opening size (Width) |
13 3/4" |
Canadian Standard (emissions) |
CSA B415.1-10 |
| Door opening size (Height) |
10" |
Warranty |
Limited lifetime |
| Glass type |
Ceramic glass |
Shipping weight |
650 lb (295 kg) |
